EGT Probe Exhaust Gas Temperature Sensor - Compact Size - 1/8" Diameter

OVERVIEW

• EGT-CP series
• Probe diameter 1/8 inch (0.125 inch)
• Enclosed Tip Sensing Junction (Foul Proof)
• Response time constant: 550 milliseconds
• Includes 316 SS adjustable compression fitting

(Recommended for fuel types: All)


MADE IN THE USA


The Exhaust Gas Temperature Sensor is specifically designed for use in a wide range of applications. Made in the USA from superior materials. The Enclosed Tip sensing junction provides reliable measurements and maximum longevity.

The Exhaust Gas Temperature Probe is capable of surviving extreme vibration and heat up to 2300 degrees F (1300 degrees C). The EGT probe will fit most internal combustion engine exhaust systems from approximately .750 inch diameter up to about 4 inch diameter with nominal installation modifications. The EGT probe is 0.125" diameter (3.175 mm) with a 2.3" (58.42 mm) straight shaft. An adjustable (316 Stainless Steel) 1/8" NPT compression fitting adapter is included. The EGT probe cable lead length is 6 feet (1.8 meters) or 12 feet (3.6 meters).

The probe cable is over-braided in stainless steel for heavy-duty abrasion resistance. The signal wires are FEP insulated. Designed to deliver high performance, high temperature measurements, reliably and consistently.

These high temperature sensors are the choice for professional racing teams, R&D test labs, and enthusiasts. The EGT probes can be used for many different applications, including Karts, Drag Racing, Formula 1, NASCAR, Off Road, Snowmobiles, Aviation, and Marine Racing.

IMPORTANT NOTE: 1/8" probes are not recommended for applications with high Exhaust Gas velocity or mounting pre-turbo (choose a 3/16" OD or 1/4" OD probe). Please confirm with your instrument manufacturer that the instrument is compatible with a Type K thermocouple sensor.

Our Exhaust Gas Temperature Sensors, Accessories and Electronics are in-stock and ready for fast delivery. Need help making a selection? Use our EGT Probe Comparison Chart. For additional pricing and technical questions, contact us now to speak to an experienced application engineer.

Options:

Add a Connector?
Add a Weld Bung?
Choose Sensor Cable Length
SKU
EGT-CP-072-S211-SS-N
Availability
In Stock
0
Out of Stock
0
Price
$59.50
Add to Cart

TECHNICAL SPECIFICATIONS

Thermocouple type:

Type K

Sensing Junction:

Exposed, Ungrounded

Accuracy:

+/-0.4% of reading or about +/- 1.1°C (Special Limits of Error)

Probe Diameter:

1/8 inch (0.125 inch) (3.17 mm)

Max Tip Insertion Depth:

1.1 inch (27.94 mm)

Response Time:

550 milliseconds

Outer Sheath Material:

Inconel 600 protective sheathing

Sheath Wall Thickness:

0.015" (.38 mm), MgO insulated

Cable:

Stainless steel over-braid cable with FEP insulated conductors; 6 foot

Included Compression Fitting:

316 stainless steel, double ferrule, adjustable, 1/8 inch –27 NPT male thread
